Gas(oil) Fired Integrated Steam Boiler

Gas(oil) Fired Integrated Steam Boiler

The series of boilers adopts an excellent design concept. Through the condensing device, the heat of the flue gas is used in cascade, and the residual heat in the flue gas is fully absorbed, so that the boiler efficiency is greatly improved.

Capacity: 1-20t/h

Rated Thermal Efficiency: 100-104%

Fixed Work Stress: ≤3.82MPa

Applicable Fuel: heavy oil, diesel, natural gas, city gas, etc.

Product advantages

High thermal efficiency

The flue gas is condensed and recovered,the combustion efficiency is >98%, and the thermal efficiency is ≥104%, which can reduce fuel consumption by more than 4%.

PLC intelligent control

The self-developed PLC fully automatic intelligent control system greatly improves the reliability of boiler operation.

More corrosion resistant

The oxygen content of the feed water is less than 16%, and the boiler body material is made of silicon aluminum alloy, which is more resistant to corrosion.

Multiple protection system

Various protection systems such as water level, pressure, temperature, power supply, scale detection, etc., guarantee the safety of boiler operation in all aspects.

Long lasting

The combustion chamber is completely immersed in water, the cooling conditions are excellent, the boiler operating environment is greatly improved, and the service life of the boiler is increased.

Good sealing effect

The smoke box door and panel adopt a double-layer sealed structure, and the intelligent welding equipment can be welded at one time to prevent air leakage and smoke leakage.



Product Parameters


Types Evaporation Steam pressure Steam temperature Feed water temperature Thermal efficiency Fuel Power requirement Length * Width * Height Weight Chimney
Unit t/h MPa °C °C % V/Hz mm t mm
WNS1-1.0-Y.Q 1 ≤3.82MPa (184)
194
(204)
20 100-104 Diesel,
heavy oil,
natural gas,
city gas
380/50 3650 * 2320 * 2970 5.1 300
WNS2-1.25-Y.Q 2 4650 * 2920 * 3640 9.3 350
WNS3-1.25-Y.Q 3 5340 * 2990 * 3860 11.8 450
WNS4-1.25-Y.Q 4 6170 * 2930 * 4170 12.9 450
WNS6-1.25-Y.Q 6 6760 * 3160 * 4390 16.3 550
WNS8-1.25-Y.Q 8 7720 * 3710 * 5210 24.1 700
WNS10-1.25-Y.Q 10 7940 * 3770 * 5210 25.5 700
WNS15-1.25-Y.Q 15 9300 * 5390 * 5490 36.2 900
WNS20-1.25-Y.Q 20 9500 * 5770 * 5930 47.4 900

Note:

Due to the continuous improvement of technology, we will not notify if there is any change; please ask the headquarters of Fangkuai Boiler Co., Ltd. for detailed parameters.
